15
3. After SKIP connection or not connected.
Following are the MPCX2 controls when not linked to a receiver
Note: Hold the lower left button on start up to skip connection on start up. The controller will also time
out if a receiver is not present and will display the main menu.
Segment Selection
With no link to a receiver segment selection is functionally to select a segment to modify.
Cycles segment timer forward to desired segment
Press to save changes to segment IE time, auto horn, and
auto advance.
Cycles segment timer backward to desired segment.
Press to save changes to segment IE time, auto horn, and auto advance
Setting Time
Follow these steps to set the time on each segment desired to use.
One press of the SET TIME button will highlight the minutes
of the current segment to be edited
Additional presses will toggle between editing minutes and
seconds of the selected segment
Use the “+” or “-” keys to change the time settings for minutes
or seconds
Note: Hold the key down for fast advance
Note: Each segment has maximum time limit of 99 minutes
and 59 seconds.
Setting a time of 0:00 on a segment will delete the current
segment being modified and all segments after it
To do this using this segment first set the time to 0:00
Then press NEXT SEGMENT or PREVIOUS SEGMENT
Seg: 1 of 40 HA
0:31 Time: OFF
Strikes:0
Seg: 1 of 40 HA
0:31 Time: OFF
Strikes:0
Seg: 6 of 40 HA
5:31 Time: OFF
Strikes:0
Seg: 2 of 40 HA
0:31 Time: OFF
Seg: 6 of 40 HA
0:00 Time: OFF
Strikes:0
Seg: 5 of 5 HA
0:28 Time: OFF
Strikes:0
