Page 30
8 Dimensions
Units `U Depth Depth
mm (Inches)
Height
mm (Inches)
Approx.
Weight kg (lbs)
8816 2 390 (15.4) 88 (3.5) 7 (16)
9 Rack Mounting and Cooling
The rack unit should be installed in a 19 inch cabinet with access to the front and the
rear.
No specific air conditioning is required for the rack provided that there is free flow of
air through the rack from front to back and side to side, and that the ambient air is
maintained below 25 degrees centigrade. Racks may be stacked, but at least 1U
space should be allowed between each rack unit.
10 Power Requirements
8816
Rated Voltage 36VDC
Rated Current 1.6A MAX
Primary Protection Fuse:
Operating Voltage 36V
Fuse Rating and Type T3.15A anti-surge 20mm x 5mm glass
Location Next to DC Power Input on rear of unit
Mains Supply
The power supply unit is a free standing external type with a universal input,
therefore no mains operating voltage setting is required.
There is a mains earth lift switch located at the rear of the unit next to the fuse holder.
When operated this isolates the mains earth from the chassis of the unit. If this is
operated, earth must be maintained to the chassis of the unit by using the studio
technical earth or equivalent earthing system.
When illuminated the red led on the power switch indicates +36V power healthy.
