13 Connectors
There are five 25 way D type connectors. Connectors 1 and 2 are used for channel inputs, connector
3 for auxiliary outputs, connector 4 for master section inputs and connector 5 for master section
outputs.
The 16 line inputs are on 2 x 25way D type connectors and follow the standard pin plan used by Pro
Tools
TM
and Tascam DA88
TM
.
Circuit Shield Hi Lo
1 25 24 12
2 11 10 23
3 22 21 9
4 8 7 20
5 19 18 6
6 5 4 17
7 16 15 3
8 2 1 14
Connector 1 channel inputs 1 to 8.
Connector 2 channel inputs 9 to 16.
The same pin arrangement is used on connectors 3, 4 and 5 to provide the following circuits.
Connector 3:
8: PRE FADE INSERT LEFT SEND
7: PRE FADE INSERT RIGHT SEND
6: INSERT MIX LEFT SEND
5: INSERT MIX RIGHT SEND
4: AUX BUS SEND
3: -
2: -
1: -
Connector 4:
8: PRE FADE INSERT LEFT RETURN
7: PRE FADE INSERT RIGHT RETURN
6: INSERT MIX LEFT RETURN
5: INSERT MIX RIGHT RETURN
4: 2 TRACKS LEFT RETURN
3: 2 TRACKS RIGHT RETURN
2: 2 TRACKS LEFT BUS INPUT
1: 2 TRACKS RIGHT BUS INPUT
Connector 5:
8: MAIN MIX LEFT OUTPUT
7: MAIN MIX RIGHT OUTPUT
6: MONITOR MAIN SPEAKER LEFT OUTPUT
5: MONITOR MAIN SPEAKER RIGHT OUTPUT
4: MONITOR ALTERNATE SPEAKER LEFT OUTPUT
3: MONITOR ALTERNATE SPEAKER RIGHT OUTPUT
2: CUE LEFT OUTPUT
1: CUE RIGHT OUTPUT
There are two unbalanced mono 1/4" jack outputs
