Page 21
6 Recall
Introduction
The 8816 Recall system is a simple and straightforward way of storing and Recalling
settings of the unit within the Recall or Session folder systems using a PC or a Mac
via USB. Most controls with the exception of the power switch, ADC option and
meters can be stored and Recalled, with the added advantage that all switch
parameters can be instantly reset without the need of time consuming manual
intervention.
N.B. Minimum display resolution is 1024 x 768
Setups
The 8816 forms part of the 88 outboard range which also includes the 8804 fader
option for the 8816. All of 88 units can be connected to a PC or Mac using a USB
hub to form a session that can be stored and Recalled.
The Recall system automatically finds the types of units that are plugged into the
USB hub. The only action necessary is if two 8816 units form part of the same
session they will need to be set to either slave or master via the slave bus switch.
See rear panel for details.
