Neve 8816 - Page 34

Page 32
Monitor source pre/post ADC Insert
NOTE: The monitor source can be set to pre or post ADC insert using jumpers within
the unit. Please consult your Neve dealer if the following Information is not clear.
ADC
JUMPER SETTINGS
MON SOURCE PRE ADC INSERT
,
DEFAULT SETTING
MON SOURCE POST ADC INSERT
