SECTION 4 – LUBRICATION AND MAINTENANCE
4–120
AIR COMPRESSOR (IF INSTALLED)
• CNH engine:
The air compressor 1 is installed near the engine and
needs no further maintenance.
225
• Iveco engine:
The air compressor 1 is installed onto the engine and
needs no further maintenance.
226
Every 50 operating hours, drain the condensated
water from the air reservoir through cock 2.
Two unions 3 are installed to attach pneumatic ser-
vice tools and for cleaning purposes.
The inner thread of the union is 1/2 GAZ CYL.
One is located under the air reservoir.
227
