SECTION 5 – FAULT FINDING
5–12
Gearshifting
If not possible to select gears electronically (gearshift
selector switch from the cab), it can be done
manually, proceeding as follows:
1. Park the combine level (if possible).
2. Raise the header and engage the header safety
latch. Stop the engine.
3. Block the wheels adequately to prevent the
combine from running.
4. Loosen the bolts to remove traction gearbox
cover plate 3.
3
5. Loosen four bolts 1 and remove the electric
motor.
4
6. Use the special tool (located at the left-hand side
of the straw elevator) to turn nut 2 underneath the
electric motor.
5
