ChipSHOUTER Users Manual: Specifications
18
USA (FCC) ........................ 47 CFR 15 subpart B. This product is
considered and exempt device per clause
15.103.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference
and (2) this device must accept any interference re-
ceived, including interference that may cause
undesired operations. You must discontinue use of
this device if it causes interference to another us-
er, and remedy the interference before continuing
operation of this device.
I/O Characteristics
Serial command interface .............. 3.3V CMOS Serial, 115200 baud, 8N1
Protocol ............................. (1) ASCII command prompt
(2) Binary
Serial connection ..................... RJ12 connector with GND, TX/RX,
3.3V output, and switchable pulse/arm
pin.
Hardware trigger connector type ...... SMB connector, center-positive
Hardware trigger threshold ........... 2V
Hardware trigger absolute max ratings -0.5V to 6.5V
Hardware trigger impedance ............ 50Ω / 1.8KΩ (Switchable)
Hardware trigger level ................ Active-high / Active-Low (Switchable)
Injected waveform monitor ............. BNC connector for mating with standard
1MΩ || 10-25pF oscilloscope input. Ad-
justable compensation trimmer for fine-
tuning match.
Voltage monitor attenuation ........... 20x attenuation
Voltage monitor output range .......... ±25V into properly matched oscilloscope
input
High Voltage Characteristics
Characteristic
Min
Typ
Max
Units
Programmable voltage range
150
500
V
Charge rate
30
40
V/ms
Charge energy
625
mJ
Measured voltage accuracy via digital
interface
±(5% + 10V)
