Fault Modes
ChipSHOUTER has several possible faults. The specific faults
can be determined via the serial interface (described in an-
other section), however the most common faults are also
described with special blink patterns and indicators on the
LEDs.
Fault
Fault Description
Probe
Probe disconnected or damaged (open).
Overtemp
Internal temperatures too high.
Panel Open
Front panel removed or not secure.
High Voltage Er-
ror
Measured high-voltage is higher/lower
than expected.
RAM CRC
RAM CRC failed.
EEPROM CRC
EEPROM CRC failed.
GPIO
GPIO state does not match expected.
Charge Error
Charge circuit error, likely DC input
voltage out-of-spec or brown-out.
Trigger
Trigger too long or invalid.
Hardware Exc
Internal hardware failure detected.
Trigger Glitch
Device triggered while disarmed.
Over Voltage
Charge voltage higher than expected.
ChipSHOUTER faults indicate unexpected operat-
ing conditions. If faults occur, carefully
read and
understand this section of the user manual to take
the proper corrective action. If it is not cle
ar what
fault has occurred, please discontinue use of the
device and contact us immediately.
