SPECIFICATIONS
SPECIFICATIONS C80 Three Axis Digital Readout System
Feb 2002Newall Measurement Systems Ltd2
Electrical
EMC and Low Voltage Compliance
BS EN 55022:1998 Class B
BS EN 55024:1998
Power Supply Unit (supplied)
100 - 240V (47 - 63Hz)
External switch-mode
Conforms to Low Voltage Directive
EN 60 950:1992/
A1:1993/ A2:1994/ A3:1996/ A4:1997
Physical
Height
265mm (10.43”)
Width
180mm (7.09”)
Depth (not including connectors)
50mm (1.97”)
Weight
2.9kg (6.38lb)
Environmental
Operating Temperature
0 to 45°C
Storage Temperature
-20 to 70°C
Environmental Conditions
Indoor Use, IP20 (IEC 529)
Relative Humidity
Maximum 80% for temperatures up to 31°C
decreasing linearly to 33% at 45°C
Disposal
At the end of its life, the C80 system should
be disposed of in a safe manner applicable to
electronic goods.
DO NOT BURN.
The casework is suitable for recycling. If you
have any doubt about how to dispose of
your unit, please return it to Newall and we
will provide this service for you.
Input
Three Spherosyn or Microsyn encoders.
Resolutions
Spherosyn or Microsyn 10
(menu selection)
5μm (0.0002”)
10μm (0.0005”)
20μm (0.001”)
50μm (0.002”)
Microsyn 5
(menu selection)
1μm (0.00005”)
2μm (0.0001”)
5μm (0.0002”)
10μm (0.0005”)
NOTE: NEWALL MEASUREMENT SYSTEMS LTD
RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE.
