Newall C80 - Mounting; Arm Mounting (Non-Adjustable); Arm Mounting (Adjustable)

Arm Mounting (Non-adjustable)
Arm Mounting (Adjustable)
MOUNTING
MOUNTING, Arm mounting C80 Three Axis Digital Readout System
NOTES
Feb 2002Newall Measurement Systems Ltd4
• The C80 can be mounted in a variety of ways, depending on the mounting assemblies purchased
with the unit:
M10 stud & fixings,
supplied as standard
Arm mount adjustable pivot assembly
Part no. 600-80290
Mounting arm assembly
Part no. 294-35670
Mounting arm assembly
Part no. 294-35670
