NewLine rs+ User Manual

83
Model
TT-6519RS
TT-7519RS
TT-8619RS
Touch
Touch Surface
Anti-glare tempered glass
Transparency
88%
Surface Hardness
7H
HID support
YES
Touch Points
10 Points in Smart system
20 Points in Windows
Writing Tools
Eraser, Stylus or Finger
Scan Speed
10ms
10 ms
10 ms
Positioning
Accuracy
Center area 1.0 – 1.5 mm / Edge area 1.2 – 2.0 mm
Communication
Interface
USB-A
Transportation/Storage
Storage
Temperature/
Humidity
-15℃~55℃/20～90％RH(Non coagulation)
Working
Temperature/
Humidity
0℃-40℃/20～80％RH(Non coagulation)
Mounting
(optional)
Wall-mounted/Floor Stand
Outline Dimension
60.87 x 37.1 x 3.74 in
1546 x 944 x 96 mm
69.69 x 42.17 x 4.29 in
1770 x 1071 x 109 mm
79.49 x 47.72 x 4.29 in
2019 x 1212 x 109 mm
Packing
Dimension
67.91 x 42.72 x
11.02 in
1670 x 1056 x 221 mm
75.59 x 46.85 x 10.83 in
1894 x 1193 x 247 mm
84.84 x 51.97 x 12.21 in
2170 x 1345 x 275mm
Net Weight
approx. 44kg
approx. 56kg
approx. 72kg
Gross Weight
57±2kg
71±2kg
90±2kg
Ports
Front Interface
Inputs
HDMI In x 1, USB (Touch) x 1, USB (Public) x 2, Microphone In x 1
Rear Interface
Inputs
HDMI In x 2, DP x 1, USB (Touch) x 4, Line Out x 1, DC Out (5V, 2A),
SPDIF out x 1, USB 2.0 (Public) x 1, USB 2.0 (Embedded) x 1, RS-232 x 1,
USB 3.0 (Public) x 1, Audio In x 1, VGA x 1, LAN In x 1, LAN Out x 1, OPS
Slots (4K@60Hz)

NewLine rs+ Specifications

General

Resolution	3840 x 2160 (4K UHD)
Brightness	350 cd/m²
Display Type	LED
Touch Points	20
Ports	HDMI, USB, VGA, Audio Out, Ethernet
VESA Mount Compatible	Yes
