NewLine rs+ User Manual

82
8 Specifications
Model
TT-6519RS
TT-7519RS
TT-8619RS
Display
Backlight
LED
Display Area
56.24 x 31.63 in
1432 x 807mm
64.97 in x 36.55 in
1652 x 930mm
74.69 in x 42.05 in
1893 x 1069mm
Active Screen Size
65 inch
75 inch
86 inch
Display Ratio
16:9
Resolution
3840 x 2160 Pixel
Display Colors
8 bit+FRC, 1.07 billion
colors
8 bit+FRC, 1.07 billion
colors
10 bit, 1.07 billion
colors
Brightness
≥ 370 cd/m
2
Contrast
4000:1
4000:1
1200:1
Response Time
≤ 8 ms
Life Time
30000 h (Min.)
Speaker
Speaker Position
Forward
Max. Power
Output
2 x 15 W
Microphone
Type
3.5 mm interface
Electrical
Power
Consumption
Maximum ≤ 250 W
Standby Mode ≤ 0.5 W
Maximum ≤ 400 W
Standby Mode ≤ 0.5 W
Maximum ≤ 450 W
Standby Mode ≤ 0.5 W
Working Voltage
AC 100 V – 240 V, 50 Hz / 60 Hz

NewLine rs+ Specifications

General

Resolution	3840 x 2160 (4K UHD)
Brightness	350 cd/m²
Display Type	LED
Touch Points	20
Ports	HDMI, USB, VGA, Audio Out, Ethernet
VESA Mount Compatible	Yes
