NewLine rs+ User Manual

48
SN
Icon Name
Icon Function
11
Object
recognition
switch
Slide the turn on or off the object recognition function.
12
New Page
Click to add a new page. Click and hold for two seconds to set the
color and the pattern of the new page.
13
Previous Page
Click to back to the previous page.
14
Next Page
Click to go to the next page.
15
Navigation
Click to show the page thumbnails.
16
Hide Smart Bar
Click to hide or show the smart bar.
17
Mode Switch
Click the icon to enter discussion mode.
18
Screenshot
Click to take a screenshot, and save the data in the display’s internal
storage.
4.6.1 Whiteboard Functions
New Page and Settings
⚫
Create a new page
In discussion mode, click to create a new page. Up to 20 pages can be created. See the
following figure:
⚫
Page settings

NewLine rs+ Specifications

General

Resolution	3840 x 2160 (4K UHD)
Brightness	350 cd/m²
Display Type	LED
Touch Points	20
Ports	HDMI, USB, VGA, Audio Out, Ethernet
VESA Mount Compatible	Yes
