Newport LDC-3706 Series User Manual

December 2019 82 LDC-3706 Series Laser Controller
SENSor:ICV:LIMit:LOW <nrf> TEC
SENSor:ICV:LIMit:LOW?
Description Sets/Reports voltage lower limit for the IC sensor.
Parameters 0 – 6.0 – Range in Volts.
Reset Value 0.0
Example SENS:ICV:LIM:LOW 0.0; Sets the lower voltage limit for the IC sensor to 0V.
SENSor:ICV:LIMit:HIGH <nrf> TEC
SENSor:ICV:LIMit:HIGH?
Description Sets/Reports voltage upper limit for the IC sensor.
Parameters 0 – 6.0 – Range in Volts.
Reset Value 6.0
Example SENS:ICV:LIM:HIGH 6.0; Sets the upper voltage limit to 6V.
SOURce[1]:AM[:STATe] <nrf> LAS
SOURce[1]:AM[:STATe]?
Description Sets/reports enabled state of laser driver analog modulation.
Parameters 0 or 1 – 0 for off, 1 for on
Reset Value
0
Example SOUR:AM 1; Sets analog modulation on.
SOURce[1]:CURRent:LIMit:HIGH <nrf> TEC
SOURce[1]:CURRent:LIMit:HIGH?
Description Sets/reports upper TEC current limit.
Parameters Upper current limit in Amps
LDC-3726 0.00 – 4.00
LDC-3736 0.00 – 8.00
LDC-37620 0.00 – 8.00
Reset Value 1.00
Example SOUR:CURR:LIM:HIGH 4; Sets the upper current limit for the TEC to 4A.
SOURce[1]:CURRent:LIMit:LOW <nrf> TEC
SOURce[1]:CURRent:LIMit:LOW?
Description Sets/reports lower TEC current limit.
Parameters Lower current limit in Amps
LDC-3726 0.00 – -4.00
LDC-3736 0.00 – -8.00
LDC-37620 0.00 – -8.00
Reset Value -1.00
Example SOUR:CURR:LIM:LOW -4; Sets the lower current limit for the TEC to -4A.
