XPS-D Controller Start-Up Manual
1.2.2 Electric Shock
Figure 2: Electrical shock symbol.
The Electrical Shock Symbol in Figure 2 may appear on labels affixed to the XPS
Series Controller/Driver. This symbol indicates a hazard arising from dangerous
voltages. Any mishandling could result in damage to the equipment, personal injury, or
even death.
1.2.3 European Union CE Mark
Figure 3: CE mark.
The presence of the CE Mark on Newport Corporation equipment means that it has
been designed, tested and certified to comply with all current and applicable European
Union (CE) regulations and recommendations.
1.2.4 “ON” Symbol
Figure 4: “ON” symbol.
The “ON” Symbol in Figure 4 appears on the power switch of the XPS Series
Controller/Driver. This symbol represents the “Power On” condition.
1.2.5 “OFF” Symbol
Figure 5: “OFF” symbol.
The “Off” Symbol in Figure 5 appears on the power switch of the XPS Series
Controller/Driver. This symbol represents the “Power Off” condition.
1.2.6 Protective Earth Symbol
Figure 6: Protective Earth symbol.
The Protective Earth Symbol in Figure 6 appears next to the ground stud at the rear of
the XPS Series Controller/Driver.
EDH0395En1031 – 09/18 2
