XPS-D Controller Start-Up Manual
2.4 Split power entry version
The XPS controller can be provided with two separated AC entries. In this case, one is
dedicated to controller logic supply and another one is providing motor drive supply. It
allows user to turn off the driver power (for safety reason for instance) without losing
control on encoder position, limit switches, etc…)
2.5 Front Panel Description
Figure 7: Front panel of XPS Controller/Driver.
TheXPS front panel is free of any connection or command device.
EDH0395En1031 – 09/18 8
