36 USB-Link™ 2 Wi-Fi Edition Installation and Setup Manual
Chapter 3 • Installing the Drivers and Setting Up the Device
The Tools Menu
The Tools menu provides the following features:
•Ping
• Options
Ping
The Ping feature uses the PING protocol to check for the presence of a device on
the network.
To check for a device:
1 Select Tools from the USB-Link™ 2 Explorer menu bar.
2 Select Ping.
Figure 3.20 Ping Dialog Box
3 Enter the IP address of the device you want to locate (e.g., 192.168.123.107).
4 Click Start.
Th
e USB-Link™ 2 Explorer searches for the device and, if found, displays
the reply
.
5 Click Stop.
6 Click the Close butt
on on the dialog box.
