NextBase NBDVR222 User Manual

10
Product appearance may differ slightly to that shown above.
Package Contents
Please check the contents of your Nextbase Dash Cam product.
Product Features
Thank you for purchasing this Nextbase™ Dash Cam product, in this section we will outline some of
the features available with this dash cam.
HD Recording Capability
1080p HD recording at 30 fps, to record the road ahead.
HD Display
Bright, clear, high definition 2.5" screen with IPS technology for a wide viewing angle.
Click & Go Pro Powered Mount
Our exclusive Click and Go Pro powered magnetic car mount to easily install and remove
your Dash Cam with just one hand. Supplied with both adhesive and suction fittings.
G Sensor / File Protection
In the event of an impact the device will automatically 'protect' the recording, stopping the file from
being over-written. This can also be performed manually, by pressing the ‘protect’ button.
Individual files can also be 'protected' when viewed within playback mode.
Automatic Start / Stop Technology
As soon as the vehicle ignition is turned on, your Dash Cam will start to record automatically.
When the ignition is turned off, the Dash Cam will perform an automatic shutdown process.
Intelligent Parking Mode
Intelligent Parking Mode triggers recording automatically when motion is detected, keeping your
car safe when parked.
Built-in Microphone & Speaker
Record audio to compliment the video recordings.
Nextbase Cloud™ Service
View and share your footage online using the MyNextbase Cloud™ service. Upload your video to
the Nextbase™ server to get a shareable link to send to friends, insurers, and social media. Upload your
videos via the file upload area on . The uploaded file will be deleted after 30 days,Mynextbase.com
when the link will also expire.
Nextbase™ 222 Dash Cam
Click & Go
Powered Mounts:
Suction and Adhesive
Car Power Cable (4m)
USB Connection Cable
222 Quick Start Guide
Cable Tidy Tool
Your Dash Cam to record the road ahead
Charge your Dash Cam in car
using the Car Power Cable
Connect your Dash Cam to a PC
Quickly get your Dash Cam up and
running using Quick Start Guide.
Use the Cable Tidy Tool to stow the
power cable within the lining of your car.
Two mount attachments
for you to choose
between.

NextBase NBDVR222 Specifications

General

Night vision	Yes
Product color	Black
G-shock sensor	No
Country of origin	China
Number of cameras	1
Maximum frame rate	30 fps
Power cable length	4 m
Aperture range (F-F)	1.6 - 1.6
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	140 °
Video compression formats	MP4
Main camera sensor resolution	2.12 MP
Battery life	15 min
Battery weight	6 g
Output current	2 A
Output voltage	3.7 V
Battery capacity	280 mAh
Operating voltage	12 V
Power source type	Battery, Cigar lighter
Input operation voltage (max)	24 V
Bundled software	MyNextbase Player - Windows 7/ OSX 10.9
Storage temperature (T-T)	-20 - 45 °C
Display diagonal	2.5 \
Cables included	Mini-USB
Quantity per pack	7 pc(s)
Accessories included	Vdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Compatible memory cards	MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Quantity per pallet	720 pc(s)
Master (outer) case width	280 mm
Master (outer) case height	370 mm
Master (outer) case length	330 mm
Master (outer) case weight	9300 g
Customs product code (TARIC)	8525890000
Quantity per master (outer) case	20 pc(s)
Master (outer) case GTIN (EAN/UPC)	5060384255668
Export Control Classification Number (ECCN)	EAR99
Package depth	6.62 mm
Package width	15.3 mm
Package height	12.5 mm
Package weight	403 g

Weight and Dimensions

Depth	46 mm
Width	82 mm
Weight	79 g
