NextBase NBDVR222 User Manual

16:04:37 01/02/2019
Audio Recording ON
Can be switched OFF in the Dash Cam Setup Menu.
Parking Mode ON
Can be switched OFF in the Dash Cam Setup Menu.
File is protected
This will appear either when the ‘protect’ button is manually pushed, or
when the G Sensor is triggered.
Recording Duration
Up to 3 minutes. Length can be changed in the Dash Cam Setup Menu. .
Time Display
Can be manually changed in the Dash Cam Setup Menu.
Date Display
Can be manually changed in the Dash Cam Setup Menu. .
Photo Mode
The key below explains the various information displayed
on the screen when your Dash Cam is in Photo mode.
Playback Mode
The key below explains the various information displayed
on the screen when your Dash Cam is in Playback mode.
Video Mode
The key below explains the various information displayed on the screen when your
Dash Cam is in Video mode, some icons will only be displayed once the relevant function
has been selected within the Video menu, as described below.
1
2
3
4
5
6
Photo Mode
Press ‘Mode’ Buttton to toggle between Video,
Photo, and Playback.
Time Display
Can be manually changed in the Dash Cam
Setup Menu.
Date Display
can be manually changed in the Dash Cam
Setup Menu.
7
8
9
2
MODE
MENU
OK
5
1
64
3
7
16:04:37 01/02/2019
MODE
MENU
OK
8
9
10
MODE
MENU
OK
11
16:04:37
01/02/2019
160359_01022019_001.JPEG/MP4
1234 ABC 1234 ABC
:PREV:NEXT
MODE: OK:
12
13
15 1614
Nextbase Logo Stamp
File Name
Photos are saved as JPEGs.
Videos saved as .MP4.
Protected File Icon
File can be protected/unprotected by
pressing the Menu button while previewing
files in playback mode.
Info Stamps
License plate number, Dash Cam model,
Time & Date. These can be turned ON/OFF
in the menus.
Playback options
Press Record to Play/Pause. Press Mode to
Stop and return to file navigation.
Navigation
Press the buttons on the right of the Dash
Cam to scroll through the photos and
videos stored on the SD card.
Time/Date Display
Can be manually changed in
Dash Cam Settings.
11
12
13
14
10
15
16
23

NextBase NBDVR222 Specifications

General

Night vision	Yes
Product color	Black
G-shock sensor	No
Country of origin	China
Number of cameras	1
Maximum frame rate	30 fps
Power cable length	4 m
Aperture range (F-F)	1.6 - 1.6
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	140 °
Video compression formats	MP4
Main camera sensor resolution	2.12 MP
Battery life	15 min
Battery weight	6 g
Output current	2 A
Output voltage	3.7 V
Battery capacity	280 mAh
Operating voltage	12 V
Power source type	Battery, Cigar lighter
Input operation voltage (max)	24 V
Bundled software	MyNextbase Player - Windows 7/ OSX 10.9
Storage temperature (T-T)	-20 - 45 °C
Display diagonal	2.5 \
Cables included	Mini-USB
Quantity per pack	7 pc(s)
Accessories included	Vdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Compatible memory cards	MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Quantity per pallet	720 pc(s)
Master (outer) case width	280 mm
Master (outer) case height	370 mm
Master (outer) case length	330 mm
Master (outer) case weight	9300 g
Customs product code (TARIC)	8525890000
Quantity per master (outer) case	20 pc(s)
Master (outer) case GTIN (EAN/UPC)	5060384255668
Export Control Classification Number (ECCN)	EAR99
Package depth	6.62 mm
Package width	15.3 mm
Package height	12.5 mm
Package weight	403 g

Weight and Dimensions

Depth	46 mm
Width	82 mm
Weight	79 g
