Product Warnings
Failure to heed the following warnings could result in an accident or collision resulting in death or
serious injury.
Distraction Warning
This Dash Cam is intended to enhance the situational awareness when used properly. If used improperly,
you could become distracted by the display, which could lead to an accident causing serious personal
injury or death. DO NOT seek to access the information stored on the Dash Cam or change the device
settings whilst driving. Information stored on the Dash Cam should be reviewed only when your vehicle is
stationary, and you are parked in a safe place in compliance with local laws.
The Dash Cam settings should only be changed when your vehicle is stationary, and you are parked in a
safe place in compliance with local laws. Always maintain awareness of your surroundings and do not
stare at the display or become distracted by the display. Focusing on the display could cause you to miss
obstacles or hazards. Use the Dash Cam at your own risk.
Do not change settings, or access any functions requiring prolonged use of the Dash Cam controls while
driving. Pull over in a safe and legal manner before attempting such operations.
Video playback upon devices with displays which are visible to the driver, is prohibited or restricted in
some countries or states. Please adhere to these laws.
Vehicle Installation Warnings
When installing the Dash Cam in a vehicle, do not place the Dash Cam where it obstructs the driver's
view of the road or interferes with vehicle operating controls, such as the steering wheel, foot pedals, or
transmission levers. Do not place unsecured on the vehicle dashboard.
Do not place the Dash Cam in front of or above any airbag.
Battery Warnings
Lithium-ion batteries are used in most Nextbase™ Dash Cams. If these guidelines are not followed,
batteries may experience a shortened life span or may present a risk of damage to the Dash Cam, fire,
chemical burn, electrolyte leak, and/or injury.
- Do not disassemble, modify, remanufacture, puncture, or damage the Dash Cam or batteries.
- Do not remove or attempt to remove the non-user replaceable battery.
- Do not expose the Dash Cam to fire, explosion, or other hazard.
- Do not expose the Dash Cam to rain or water.
Magnet Warnings
Both the Dash Cam and its mount may contain magnets. Under certain circumstances, magnets may
cause interference with some internal medical devices, including pacemakers and insulin pumps.
Devices and mounts that contain magnets should be kept away from such medical devices. Magnets
may cause damage to some electronic devices, including hard drives in laptop computers and
bank / credit or membership cards. Use caution when devices and mounts that contain magnets are
near electronic devices or bank / credit or membership cards.
05

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NextBase NBDVR222 and is the answer not in the manual?

NextBase NBDVR222 Specifications

General IconGeneral
Night visionYes
Product colorBlack
G-shock sensorNo
Country of originChina
Number of cameras1
Maximum frame rate30 fps
Power cable length4 m
Aperture range (F-F)1.6 - 1.6
Main camera resolution1920 x 1080 pixels
Main camera viewing angle140 °
Video compression formatsMP4
Main camera sensor resolution2.12 MP
Battery life15 min
Battery weight6 g
Output current2 A
Output voltage3.7 V
Battery capacity280 mAh
Operating voltage12 V
Power source typeBattery, Cigar lighter
Input operation voltage (max)24 V
Bundled softwareMyNextbase Player - Windows 7/ OSX 10.9
Storage temperature (T-T)-20 - 45 °C
Display diagonal2.5 \
Cables includedMini-USB
Quantity per pack7 pc(s)
Accessories includedVdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Compatible memory cardsMicroSDHC, MicroSDXC
Maximum memory card size128 GB
Quantity per pallet720 pc(s)
Master (outer) case width280 mm
Master (outer) case height370 mm
Master (outer) case length330 mm
Master (outer) case weight9300 g
Customs product code (TARIC)8525890000
Quantity per master (outer) case20 pc(s)
Master (outer) case GTIN (EAN/UPC)5060384255668
Export Control Classification Number (ECCN)EAR99
Package depth6.62 mm
Package width15.3 mm
Package height12.5 mm
Package weight403 g
Weight and Dimensions IconWeight and Dimensions
Depth46 mm
Width82 mm
Weight79 g
