19
Set Time
00 0000: :
Set Date Format
DD / MM / YY
Set Date
01 01 2019/ /
Initial Setup Complete
Initial setup is complete.
You can change other settings
if required from within
the menus
First Time Use Screens
To ensure the set up of this Dash Cam is as quick and simple as possible, there is an easy to follow
First Time Use’ menu.
This menu is used to set Language, Time, and Date.
This menu will appear when:
1. The Dash Cam is first turned on.
2. There has been a Firmware Update applied to the Dash Cam and ‘Keep User Settings’ has been
set to OFF. If It is set to ON, your Dash Cam will start normally, with your settings intact.
3. After the Dash Cam’s settings have been reset, by using the ‘Default Settings’ option in
the Setup Menu.
Follow the on-screen instruction to select the Language, Time, and Date.
Note:
- The First Time Use menu is in place to get you up and running quickly and smoothly.
The settings you choose during First Time Use can be changed at any later time in the setup menus.
MODE
MENU
OK
First Time Use
Use the UP and DOWN buttons
to select required function and
press OK to confirm selection.
Enter
Back
Enter
Back
Enter
Back
Enter
Back
Enter
Enter
Language
Espanol
Deutsch
Dansk
English
Language
Espanol
Deutsch
Dansk
English

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NextBase NBDVR222 and is the answer not in the manual?

NextBase NBDVR222 Specifications

General IconGeneral
Night visionYes
Product colorBlack
G-shock sensorNo
Country of originChina
Number of cameras1
Maximum frame rate30 fps
Power cable length4 m
Aperture range (F-F)1.6 - 1.6
Main camera resolution1920 x 1080 pixels
Main camera viewing angle140 °
Video compression formatsMP4
Main camera sensor resolution2.12 MP
Battery life15 min
Battery weight6 g
Output current2 A
Output voltage3.7 V
Battery capacity280 mAh
Operating voltage12 V
Power source typeBattery, Cigar lighter
Input operation voltage (max)24 V
Bundled softwareMyNextbase Player - Windows 7/ OSX 10.9
Storage temperature (T-T)-20 - 45 °C
Display diagonal2.5 \
Cables includedMini-USB
Quantity per pack7 pc(s)
Accessories includedVdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Compatible memory cardsMicroSDHC, MicroSDXC
Maximum memory card size128 GB
Quantity per pallet720 pc(s)
Master (outer) case width280 mm
Master (outer) case height370 mm
Master (outer) case length330 mm
Master (outer) case weight9300 g
Customs product code (TARIC)8525890000
Quantity per master (outer) case20 pc(s)
Master (outer) case GTIN (EAN/UPC)5060384255668
Export Control Classification Number (ECCN)EAR99
Package depth6.62 mm
Package width15.3 mm
Package height12.5 mm
Package weight403 g
Weight and Dimensions IconWeight and Dimensions
Depth46 mm
Width82 mm
Weight79 g
