NextWave Digital SHARK LCD - Axes Position Fields Explained

14 Shark HD 500 Series User’s Manual
The Axis position fields show the current location of the
axis. Pressing a field button opens the edit window for that
axis.
Axes Position Fields
X and Y Position
fields See page 15
Z Position field
See page 16,17
This space intentionally left blank:
