6 Shark HD 500 Series User’s Manual
Basic parts
LCD touch screen
USB drive port
Special Pendant cable
Connects to
control box
Z Touch plate port
The touch screen buttons can be activated
using your fingertip, a pencil eraser or a
soft-tipped stylus (not included)
NOTE: The Pendant cable has a
special pin configuration. A
standard VGA cable can not be
substituted – it will not work.
