nextys DCW20 - Page 17

DCW20 User Manual rev. 5
Page 17/34
Address
Type
R/W
Unit
Min.
Max.
Description
1: Enabled
0x1032
UINT16
R/W
1s
1
3600
PC shutdown delay.
0x1033
UINT16
R/W
1s
1
600
PC shutdown time.
0x1034
UINT16
R/W
1s
1
60
PC restart minimum time.
0x1035
UINT16
R/W
0.1A
0
20
PC off detection current threshold.
0x1036
UINT16
R/W
1s
1
60
PC off detection timer.
0x1100
DATE
R/W
1
0
1
Battery installation date
0x1104
UINT16
R/W
1
0
65535
Battery charge cycles
Metering
0x2000
SINT16
R
0.1V
0
60
Input voltage.
0x2001
SINT16
R
0.1A
0
40
Input current
0x2002
SINT16
R
0.1V
0
60
Output voltage.
0x2003
SINT16
R
0.1A
0
40
Output current.
0x2004
SINT16
R
0.1V
0
60
Battery voltage.
0x2005
SINT16
R
0.1A
-25
25
Battery current.
0x2006
SINT16
R
0.1V
0
60
Auxiliary voltage.
0x2007
SINT16
R
0.1A
0
20
Auxiliary current.
0x2008
SINT16
R
0.1°C
-40
85
External temperature.
0x2009
SINT16
R
0.1mΩ
0
3000
Battery internal resistance.
0x200A
SINT16
R
0.1%
0
100
Battery charge percent.
0x200B
SINT16
R
0.1Ah
0
10000
Battery charge capacity.
0x2010
UINT16
R
1cycle
0
65535
Boot cycles.
0x2020
UINT32
R
1h
0
500000
Operating time.
0x2022
UINT32
R
1h
0
500000
Battery operating time.
Commands
0x3000
BIT
W
1
0
1
Perform Ri measurement.
0x3001
BIT
W
1
0
1
Shutdown.
0x3002
BIT
W
1
0
1
Reset device.
State (see §4.4)
0x4000
BIT
R
1
0
1
Battery charging.
0x4001
BIT
R
1
0
1
Battery floating.
0x4002
BIT
R
1
0
1
Battery discharging.
0x4010
BIT
R
1
0
1
Battery disconnected.
0x4011
BIT
R
1
0
1
Battery Ri too high.
0x4012
BIT
R
1
0
1
Battery under temperature.
0x4013
BIT
R
1
0
1
Battery over temperature.
0x4014
BIT
R
1
0
1
Battery lifetime elapsed.
0x4015
BIT
R
1
0
1
Battery charge failure.
0x4016
BIT
R
1
0
1
Battery SoC < 25%.
0x4017
BIT
R
1
0
1
Battery over discharge current.
0x4018
BIT
R
1
0
1
Battery low.
0x4019
BIT
R
1
0
1
Battery deep discharged.
0x4020
BIT
R
1
0
1
USB powered.
0x4021
BIT
R
1
0
1
Cold start.
0x4022
BIT
R
1
0
1
PC shutdown.
0x4023
BIT
R
1
0
1
PC power off.
0x4024
BIT
R
1
0
1
External temperature sensor presence.
0x4025
BIT
R
1
0
1
Inhibit.
0x4026
BIT
R
1
0
1
Output disabled.
0x4027
BIT
R
1
0
1
Auxiliary output disabled.
0x4030
BIT
R
1
0
1
Backup.
DCW20_040-02-700-005-EH-1117
