32
TROUBLESHOOTING
PROBLEM SOLUTION
Power
System will not Power up a) C-6 Controller must be plugged into an
unswitched AC outlet.
b) Power cord must be plugged into C-6
Controller
Keypads will not power up Check connections and polarity of control and
common wires from controller to Keypads.
Keypads
Keypads do not show source names a)Check C-6 Controller Setup Menu ‘Naming
Keypads’
b)See Instructions Programming section:
Naming Keypads
Tuner
Poor reception a) Are antennas connected?
b)Reposition antennas to improve reception.
No stations in presets Stations must be stored in Presets. See
Instructions Programming section: Tuner
Audio
No Audio From Source a) Is source ON?
b) Is source line audio out connected to
appropriate source input on C-6 Controller?
c) Is source playing?
No Audio In Zone a)Are speakers connected?
b)Is Zone ON?
c)Is Zone volume turned up?
No Paging Audio Signal In Zones a)Be sure page audio source is connected to
the Page Audio jack on the C-6.
b)Be sure 12V Page Trigger input is
connected. Check polarity.
C)Be sure Page trigger device is outputting
12-24VDC.
No Audio in Expansion Zones a)Check connection of 52 pin ribbon cable.
b)See Troubleshooting sections: ‘No Audio
From Source’ and ‘No Audio In Zone’.
Video
No Video From Source a) Is source ON?
b) Is source composite video out connected to
appropriate source video input on C-6
Controller?
c)Is source playing?
No Video In Zone a)Is TV or video display connected to the
appropriate zone video output?
b)Is Zone ON?
c)Is TV or video display switched to correct
input?
No Paging Video Signal in Zone a)Be sure page video source is connected to
the Page video jack on the C-6.
b)Be sure 12V Page Trigger input is
connected. Check polarity.
C)Be sure Page trigger device is outputting
12-24VDC.
No Video in Expansion Zones a)Check connection of 52 pin ribbon cable.
