WIND DATA
4-18
5.5.5 Battery voltage [BAT], option
The text [BAT] will display battery voltage. The voltage is measured
inside the instrument and will not compensate for any voltage drop
caused by installation.
5.5.6 Boat speed [BSP], option
The text [BSP] will display boat speed (water speed). The text
[BSP] will toggle with selected unit, i.e. (KTS), (KMH) or (MPH).
As an option, you may add or remove displaying boat speed
[BSP], trip log [TRP] and water temperature [TMP]. See further
under calibration.
5.5.7 Trip log [TRP], option
The text [TRP] is displayed and will show trip distance from 0.00 to
99.9 nautical miles, kilometre or miles. After 99.9, 0.00 is displayed.
Clear trip by pressing CLEAR.
5.5.8 Water temperature [TMP], option
The text [TMP] is displayed with water temperature in Celsius or
Fahrenheit.
This function require a NX2/Nexus or Star log transducer.
5.5.9 Trim function for optimum Wind angle or speed, option
The text [TRM] and [OFF] is displayed when this function is off. The
trim function can be used as an aid to keep the correct tacking
angle or to discover speed changes caused by sail or rig trimming.
Some of the functions can only be used when the Wind Data is
connected to Nexus Network.
As the first example we will use [TRM AWA] (TRiM Apparent Wind
Angle).
To trim on wind angle deviation, select the text:
Press CLEAR, the display will flash. Select [AWA] with MINUS and
confirm with SET.
Select the level of dampening [d0-d9] and confirm with the SET.
The default (or latest used) Wind angle is displayed. You may
accept the proposed angle by pressing the SET or enter a new
Wind angle with PLUS, MINUS and PAGE before confirming with
SET.
The entered Wind angle will be lost when power off. You may
