Appendix A Device-Specific Information
Note Refer to Table 7-9, X Series PCI Express/PXI Express/USB Mass
Termination/USB BNC Device Default NI-DAQmx Counter/Timer Pins, for a list of
the default NI-DAQmx counter/timer pins for this device. For more information
about default NI-DAQmx counter inputs, refer to Connecting Counter Signals in the
NI-DAQmx Help or the LabVIEW Help.
Figure A-17 shows the pinout of the NI USB-6361 BNC. For a detailed description of each
signal, refer to the I/O Connector Signal Descriptions section of Chapter 3, Connector and LED
Information.
