Part Number 12762 Rev 1.1 | April 30, 2014 ABOUT EXPANSION OPTIONS
About Option Cards
12 NETWORK CONTROLLER 3E & 6E MOUNTING AND WIRING GUIDE |
Installing an Option Card
For option-specific details, see the mounting & wiring document that accompanies
the particular option card. The following procedure provides a basic set of steps.
Procedure 2 Mounting an option card in a T-300E or T-600E controller.
Step 1 If a station is running, stop it using the platform Application Director view.
Step 2 Remove power from the controller—see the previous Warning.
Step 3 Remove the cover. See “Removing and Replacing the Cover,” page 10.
Step 4 If the optional NiMH battery/bracket assembly is installed, remove it by
taking out the four screws holding it place, setting them aside for later. Two
of these screws will also secure the option card, once installed.
a Unplug the battery from the connector on the controller’s base board.
b Remove the blanking plate from the option slot to be used.
Step 5 If no optional NiMH battery/bracket assembly is installed, remove the
blanking plate for the option slot to be used, retaining the two screws.
Table 1 JACE-3E and JACE-6E Controller Option Cards.
Option Description Notes
NPB-2X-485 Dual, optically-isolated, RS-485
adapter with two 3-position remov-
able screw-terminal connector plugs.
If installed in Option slot 1, ports operate
as COM3 and COM4. If two 485 option
cards, ports are COM3, COM4 for Option
slot 1, and COM5, COM6 for Option slot 2.
NPB-LON FTT-10A LON (LonWorks) adapter
with a 2-position removable
screw-terminal connector plug.
Port operates as LON1 if only one LON
option, or LON2 in slot 2 if two LON cards.
NPB-232 Single port RS-232 adapter, with a
DB-9M connector. Supports baud
rates up to 115200.
If installed in option slot 1, port operates as
COM3. If two 232 option cards, ports are
COM3 for Option slot 1 and COM4 for
Option slot 2.
NPB-GPRS-W
NPB-GPRS
GSM cellular modem card using
GPRS (General Packet Radio Ser-
vice), with onboard socket for SIM
card, and a Wyless SIM.
Includes SMA coax tilt-and-swivel antenna.
The NPB-GPRS-W model is bundled with a
Wyless-provisioned SIM card. The
NPB-GPRS model does not include a SIM
card.
NPB-ZWAVE
-US
or
-EU
Z-Wave wireless serial gateway
between the JACE’s NiagaraAX sta-
tion and an RF wireless Z-Wave
domain. Includes RP-SMA coax
tilt-and-swivel antenna.
-US model is 908.42 MHz for U.S. usage
-EU model is 868.42 MHz for European
usage. If installed in option slot 1, card
operates as COM3.
NPB-SED-001 Sedona Framework option card with
both wireless 6LoWPAN and wired
RS-485 port, based on the Jennic
JN5139 wireless microcontroller.
Includes stub antenna.
Enables JACE to operate as wireless net-
work coordinator and 6LoWPAN tunnel, to
integrate wireless Sedona-based devices in
the hosted station. Card uses one COM
port, e.g. COM3 if slot 1.
NOTE: COM port used is not available in
the hosted NiagaraAX station, but is
reserved for future MS/TP support.
