Part Number 12762 Rev 1.1 | April 30, 2014 ABOUT THIS GUIDE
Related Documentation
4 NETWORK CONTROLLER 3E & 6E MOUNTING AND WIRING GUIDE |
About This Guide
This document covers the mounting and wiring of the Tridium®
JACE-3E (T-300E)
and JACE-6E (T-600E) controllers. It assumes that you are an engineer, technician,
or service person who is performing control system installation. Instructions in this
document apply to the following products:
Note Not covered in this document is the Niagara
AX
software installation and
configuration required for a fully functioning unit. Refer to the JACE
Niagara AX Install and Startup Guide for this information.
In addition, the mounting and wiring of JACE expansion options are
covered in separate documents. See “Related Documentation”, and also the
section “About Expansion Options,” page 11.
Related Documentation
For more information on configuring and using the JACE-3E or JACE-6E controller,
refer to the following documents:
• JACE NiagaraAX Install and Startup Guide
• JACE Data Recovery Service (SRAM Support) - Engineering Notes
• T-IO-16 Installation and Configuration Guide
• T-IO-34 Installation and Configuration Guide
• Various option card installation documents, such as:
•NiagaraAX Ndio Guide
•NiagaraAX User Guide
Model Description
T-300E DIN mount JACE-3E controller, using PowerPC 405 400Mhz processor, 256MB
DDR2 RAM, 128MB Serial Flash, 512MB Static RAM (SRAM).
Powered by one of the two separate plug-in power supply modules, or by wall
mount AC power adapter. Controller supports optional I/O expansion modules
and internal communications option cards.
NOTE:
NiagaraAX-3.7.105 or later is required for a JACE-3E (T-300E).
T-600E,
T-600E-USA
DIN mount JACE-6E controller, using PowerPC 440 524Mhz processor, 256MB
DDR RAM, 128MB Serial Flash, 512MB Static RAM (SRAM).
Powered by one of the two separate plug-in power supply modules, or by wall
mount AC power adapter. Controller supports optional I/O expansion modules
and internal communications option cards.
NOTE:
NiagaraAX-3.6.47 or later is required for a JACE-6E (T-600E).
NPB-PWR 24Vac/dc input/15Vdc output power supply module, DIN mountable.
NPB-PWR-UN 120–240Vac universal input/15Vdc output power supply module, DIN mountable.
WPM-
XXX
Wall-mount, Class 2 universal AC power adapter, with different models available,
where -
XXX
is either: -US, -EUR, or -UK (vary by AC wall plug).
• NPB-LON Option Install Sheet • NPB-2X-485 Option Install Sheet
• NPB-232 Option Install Sheet • NPB-GPRS Modem Install Sheet
• NPB-ZWAVE Option Install Sheet • NPB-SED-001 Option Card Install Sheet
