64 NIBE F1330
Control
Menu 6.7.18 Heatdump intensif. [U]
The amplification for the shunt (SV-VD) is chosen here. For
example, a 2 degree difference between the flow line and
the calculated flow line with 5 in amplification gives 10
secs/time period controlling the shunt. The value is adjust-
able between 1 and 10. Default values: 1.
Menu 6.7.19 Periodtime cooldump [U]
The time period for the shunt (SV-KD) is chosen here. The
value is adjustable between: 1 and 500. Default values: 30.
Menu 6.7.20 Cooldump intensif. [U]
The amplification for the shunt (SV-KD) is chosen here. For
example, a 2 degree difference between the flow line and
the calculated flow line with 5 in amplification gives 10
secs/time period controlling the shunt. The value is adjust-
able between 1 and 10. Default values: 1.
Menu 6.7.21 Opening cooldump [U]
Number of seconds per time period that the acc mixing
valve must be open when the ”Start of active cooling” op-
erating mode occurs.
The value is adjustable between: off, 1 and 100 secs.
Default values: Off.
Menu 6.7.22 Brinepump cont. cool [U]
Select if the Master’s brine pump is to be run intermittently
(3 of 15 min) in check mode. Default values: No.
Menu 6.7.23 Max compr. AC [U]
Select maximum number of compressors that may be used
to produce cooling. The value is adjustable between: 1 and
all. Default values: all.
Menu 6.7.24 Heatdump 24 h funct. [U]
The time period for the shunt (SV-KD) is chosen here. The
value is adjustable between: 1 and 500. Default values: 30.
Menu 6.7.25 Return [U]
Pressing the enter button returns you to Menu 6.7.0.
Menu 6.8.0 Cooling settings [N]
Pressing the enter button takes you to sub-menus with the
cooling settings. Only shown when cooling accumulator is
selected in menu 9.1.10.
Menu 6.8.1 Cool acc temperature [N]
Shows the current temperature on the cooling accumulator
sensor (KBack).
Menu 6.8.2 Brine collector [N]
Shows the current temperature on the collector for the
brine (KB-KO).
Menu 6.8.3 Cooling curve [U]
The selected curve slope (cooling curve) is shown here). The
value can be set between 1 and 3. The factory setting is 2.
Menu 6.8.4 Offset cooling curve [U]
The selected cooling curve offset is shown here. The value
can be set between -10 and +10. The factory setting is 0.
Menu 6.8.5 Start temp. heating [U]
Outdoor temperature (menu 4.0) at the outdoor sensor
(UG) when the heat pump is permitted to produce heat.
The value can be set between -30 and 40 °C. The factory
setting is 20 °C.
Menu 6.8.6 Start temp. cooling [U]
Outdoor temperature (menu 4.0) at the outdoor sensor
(UG) when the heat pump is permitted to produce cooling.
The value can be set between -30 and 40 °C. The factory
setting is 25 °C.
Menu 6.8.7 Temp. to cool. acc. [U]
The desired temperature for the cooling accumulator is set
here. The value can be set between 0 and 20 °C. The fac-
tory setting is 13 °C.
Menu 6.8.8 Cooldiff for acc. [U]
The required cooling difference for the accumulator is set
here. The value is adjustable between 1 and 10 °C. The
factory setting is 2 °C.
Menu 6.8.9 Min. flow temp. [U]
The lowest flow temperature in cooling mode. The value
is adjustable between 2 and 65 °C. The factory setting is 5
°C.
Menu 6.8.10 Periodtime shunt [U]
The period time for the shunt (SV-K) is chosen here.
Adjustable between 1 and 500 seconds. The factory setting
is 60 seconds.
Menu 6.8.11 Shunt intensificat. [U]
The amplification for the shunt (SV-K) is chosen here. For
example, a 2 degrees difference between the flow and the
calculated flow line with 5 in amplification gives 10 sec/min
controling the shunt. The value can be set between 1 and
10. The factory setting is 1.
Menu 6.8.12 Return [N]
Pressing the Enter button returns you to menu 6.8.0.
Menu 6.9.0 Room sensor [N]
Shows the current temperature on the room sensor (RG05
or RG10). Pressing the enter button takes you to sub-men-
us with settings for the room sensor. Only shown when the
room unit or RG10 is selected in menu 9.1.11.
Menu 6.9.1 Room balancing [U]
Here you set the factor that determines how much a de-
viation between the desired and true room temperature
shall affect the flow temperature. The factor is adjustable
between 0 and 6 in increments of 0.1. The factory setting
is 1.0.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
