63NIBE F1330
Control
Menu 6.5.5 Max compr. to pool [U]
The maximum number of compressors that can be oper-
ated towards the pool exchanger (VX-P) is set here. The
number of compressors that currently produce pool heat is
within brackets. The value can be adjusted between 0 and
18. Factory setting is 1.
Menu 6.5.6 Return [U]
Pressing the enter button returns you to menu 6.5.0.
Menu 6.6.0 HW storage vessel [N]
Shows the current temperature in the hot water accumula-
tor. Pressing the enter button takes you to sub-menus for
the hot water accumulator settings. Only shown when hot
water accumulator is selected in menu 9.1.6.
Menu 6.6.1 Loading temperature [U]
The temperature that the control valve (SV-VVX) attempts
to reach on the hot water charging sensor (VVLG). The
value is adjustable between 40 and 60 °C. The factory set-
ting is 48 °C.
Menu 6.6.2 Per.-Time shuntvalve [U]
The period time for the control valve (SV-VVX) is set here.
Adjustable between 10 and 500 seconds. The factory set-
ting is 60 seconds.
Menu 6.6.3 Shunt intensificat. [U]
Applies to the control valve (SV-VVX). The value is adjust-
able between 1 and 10. The factory setting is 2.
Menu 6.6.4 Zero [U]
This is where you select zero for the control valve regula-
tor (SV-VVX). Adjustable between 1 and 100. The factory
setting is 95.
Menu 6.6.5 Return [U]
Pressing the enter button returns you to menu 6.6.0.
Menu 6.7.0 PCAC 4-pipe [U]
Press the enter button to go to sub-menus with cooling
settings. The menu is only displayed when ”PCAC 4-pipe”
is selected in menu 9.1.10.
Menu 6.7.1 Cooling [U]
On/Off. Can also be switched on and off using the operat-
ing mode button.
Menu 6.7.2 Cooling DM [U]
Display relevant GM.
Menu 6.7.3 Cooling flow temp [U]
Display of actual and set point value.
Menu 6.7.4 Brine out external [U]
Display of actual and set point value.
Menu 6.7.5 Cooldump temp. [U]
Display of actual and set point value.
Menu 6.7.6 Heatdump temp. [U]
Display of actual and set point value.
Menu 6.7.7 Cooling curve [U]
The selected curve slope (cooling curve) is shown here.
The cooling curve can be set to 0 and calculated cooling
flow is then (independent of outdoor temp): min cooling
temp + offset cooling curve. The value is adjustable be-
tween 0 and 3. Default values: 2
Menu 6.7.8 Offset cooling curve [U]
The selected cooling curve offset is shown here. The value
is adjustable between -10 and +10. Default values: 0.
Menu 6.7.9 Min. calc flow temp. [U]
The lowest cooling flow temperature in cooling mode is set
here. The value is adjustable between 0 and 30°C. Default
values: 25°C.
Menu 6.7.10 Starttemp. heating [U]
Outdoor temperature at which heating operation is permit-
ted. Can be crossed with start temp. cooling. The value is
adjustable between: -30°C and +40°C. Default values: 20
Menu 6.7.11 Starttemp. cooling [U]
Outdoor temperature at which cooling operation is permit-
ted. The value is adjustable between: -30°C and +40°C.
Default values: 25
Menu 6.7.12 Start passive cooling [U]
Cooling-GM where passive cooling is started. If this is set
higher than the start figure for active cooling it deactivates
passive cooling. The value is adjustable between: 10 and
500. Default values: 30.
Menu 6.7.13 Start active cooling [U]
Cooling-GM where active cooling is started. The value is
adjustable between: 10 and 500. Default values: 60.
Menu 6.7.14 GM for compr.-step [U]
Diff between compressor steps in active cooling mode. The
value is adjustable between: 10 and 500. Default values:
30.
Menu 6.7.15 Periodtime coolshunt [U]
The time period for the shunt (SV-K) is chosen here. The
value is adjustable between: 1 and 500. Default values: 30.
Menu 6.7.16 Coolshunt intensif. [U]
The amplification for the shunt (SV-K) is chosen here. For
example, a 2 degree difference between the flow line and
the calculated flow line with 5 in amplification gives 10
secs/time period controlling the shunt. The value is adjust-
able between 1 and 10. Default values: 1.
Menu 6.7.17 Periodtime heatdump [U]
The time period for the shunt (SV-VD) is chosen here. The
value is adjustable between: 1 and 500. Default values: 30.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
