67NIBE F1330
Control
Menu 9.1.7 Fixed condensing [S]
Here fixed condensing is set either On or Off. The factory
setting is Off.
Menu 9.1.8 Additive [S]
The type of additional heat that is engaged is set here. The
options are: Off, Electricity, Oil or Electri/Oil. The factory
setting is Off.
Menu 9.1.9 Outdoor air collect [S]
Whether an outdoor air collector is to be connected is set
here.
Can be set On or Off. The factory setting is Off.
Menu 9.1.10 Cooling [S]
The type of cooling system is set here. Selectable modes
are: ”PCAC 4pipes” “Off”, ”HPAC base card”, ”HPAC ex-
pansion card 11”, ”Cooling accumulator”, “PKM 2 pipes”
and “PKM 4 pipes”. The factory setting is “Off”.
Menu 9.1.11 Room control mode [S]
Here the type of room control connected is set. Selectable
modes are Off, Thermostat, RG05 or RG10. The factory
setting is Off.
Menu 9.1.12 Hot water with additional heat [S]
Whether additional heat is to be engaged during hot water
charging is selected here if any compressor that is normally
available for hot water production prioritises heating.
Possible modes are “On” or “Off”. The factory setting is
“Off”.
Menu 9.1.13 Return [S]
Pressing the enter button returns you to menu 9.1.0.
Menu 9.2.0 Floor drying setting [S]
Pressing the enter button takes you to sub-menus for the
floor drying settings.
Menu 9.2.1 Op-mode Floor drying [S]
The operating mode for the floor drying function is set
here. Selectable modes are:
Off: Normal operation, i.e. the floor drying function is
switched off.
Own program: Two fixed temperatures in two periods are
adjustable in menu 9.2.3 to 9.2.6.
Fixed program: The flow temperature starts day 0 at 20
°C and increases each day by 5 °C. Day 5 the temperature
has reached 45 °C, which is maintained on days 6 and 7.
The program is ended on days 8 to 12 with the tempera-
ture dropping by 5 °C each day. The factory setting is Off.
Menu 9.2.2 Floor drying day [S]
Here you can see which day the floor drying function is on.
It is also possible here to enter the floor drying program by
changing this value. The value is adjustable from 0 to 20
days. The factory setting is 0.
Menu 9.2.3 Nos. of days per. 1 [S]
Here you set the number of days that the flow temperature
shall maintain the temperature in menu 9.2.4 when Own
program in menu 9.2.1 is selected. The value is adjustable
between 1 and 10 days. The factory setting is 5 days.
Menu 9.2.4 Temperature per. 1 [S]
Here you set the temperature to be maintained on the flow
line sensor (FG) during period 1 when Own program is
selected in menu 9.2.1. The value is adjustable between 15
and 50 °C. The factory setting is 25 °C.
Menu 9.2.5 Nos. of days per. 2 [S]
Here you set the number of days that the flow temperature
shall maintain the temperature in menu 9.2.4 when Own
program in menu 9.2.1 is selected. The value is adjustable
between 1 and 10 days. The factory setting is 5 days.
Menu 9.2.6 Temperature per. 2 [S]
Here you set the temperature to be maintained on the flow
line sensor (FG) during period 2 when Own program is
selected in menu 9.2.1. The value is adjustable between 15
and 50 °C. The factory setting is 35 °C.
Menu 9.2.7 Return [S]
Pressing the enter button returns you to menu 9.2.0.
Menu 9.3.0 Alarm log [S]
Pressing the enter button takes you to sub-menus where
all operating disturbances and the heat pump’s status are
logged.
Menu 9.3.1.0 - 9.3.6.0 Alarm 1 - 6 [S]
Pressing the enter button takes you to sub-menus where
the status is shown for the heat pump when the differ-
ent operating disturbances have occurred. The alarms are
sorted chronologically, which means alarm 1 is always the
most recent. (When there are no alarms stored, pressing
enter has no effect). “x” in these menus symbolizes the
alarm number.
Menu 9.3.x.1 Type of alarm [S]
The alarms are shown in plain text,
for example, HP-Alarm / Sensor alarm HG, etc.
Menu 9.3.x.2 Heat pump [S]
Shows on which heat pump and module the alarm oc-
curred, e. g. Slave 1:B.
Menu 9.3.x.3 Date [S]
Shows the date when the alarm tripped.
Menu 9.3.x.4 Time [S]
Shows the time when the alarm tripped.
Menu 9.3.x.5 Outdoor temperature [S]
Shows the outdoor temperature on the outdoor sensor
(UG) when the alarm tripped.
Menu 9.3.x.6 Hot watertemperature [S]
Shows the hot water temperature on sensor (VVG) when
the alarm tripped.
