68 NIBE F1330
Control
Menu 9.3.x.7 Flow temperature [S]
Shows the flow temperature on sensor (FG) when the
alarm tripped.
Menu 9.3.x.8 Heating flow/return [S]
Shows the internal flow- (VBFA/B) and return line tempera-
tures (VBRA/B) for the heating medium to the compressor
module in question when the alarm tripped.
Menu 9.3.x.9 Brine in/out [S]
Shows the incoming (KBinA/B) and outgoing (KButA/B)
brine temperature when the alarm tripped.
Menu 9.3.x.10 Hot gas temperature [S]
Shows the hot gas temperature on sensor (HGA/B) when
the alarm tripped.
Menu 9.3.x.11 Overheating Temp. [S]
Shows the bulb temperature for the compressor module in
question on sensor (BA/B) when the alarm tripped.
Menu 9.3.x.12 Liquide line temp. [S]
Shows the fluid line temperature on sensor (VLA/B) for the
compressor module in question when the alarm tripped.
Menu 9.3.x.13 Relay status 1 - 8 [S]
Shows the relay status for relay 1 - 8 (relay 1 to the far left)
when the current alarm tripped.
Menu 9.3.x.14 Relay status 9 - 14 [S]
Shows the relay status for relay 9 - 14 (relay 9 to the far
left) when the current alarm tripped.
Menu 9.3.x.15 Compressor status [S]
Shows the compressor status at the time of the alarm.
E. g. Off / Hot water / Heat/cold / Pool.
Menu 9.3.x.16 Return [S]
Pressing the enter button returns you to menu.9.3.x.0.
Menu 9.3.7 Clear the alarm log [S]
Select Yes to clear the alarm log.
NOTE! The setting returns to No as soon as the heat pump
has implemented the action.
Menu 9.3.8 Return [S]
Pressing the enter button returns you to menu 9.3.0.
Incorrect management of the menus below
can seriously damage the heat pump!
NOTE!
Menu 9.4.0 Testing mode [S]
Pressing the enter button takes you to sub-menus that can
be used during installation to check that the correct con-
nection has been carried out.
Menu 9.4.1 Force control [S]
When this menu is set to On, the user temporarily takes
control of the relays on the selected relay card (menu 9.4.2)
in the heat pump the action was taken on. The setting au-
tomatically returns to Off, 30 minutes after the last button
was pushed or after a restart.
Menu 9.4.2 Relay card [S]
The relay card to be force operated is selected here (Base
card, Exp.card 11 or Exp.card 12). Only Base card can be
selected on Slave units. This is also valid for Master units
where no expansion card has been installed.
Menu 9.4.3 Relay 1 - 8 [S]
Shows the relay status for relay 1 - 8 (relay 1 to the far
left). It is possible to force the relay to the required posi-
tion using the enter button. The menu is only shown when
menu 9.4.1 is set to On.
Menu 9.4.4 Relay 9 - 14 [S]
Shows the relay status for relay 9 - 14 (relay 9 to the far
left). It is possible to force the relay to the required posi-
tion using the enter button. The menu is only shown when
menu 9.4.1 is set to On.
Menu 9.4.5 Return [S]
Pressing the enter button returns you to menu 9.4.0.
Menu 9.5 Return [S]
Pressing the Enter button returns you to menu 9.0.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
