Commissioning without heat pump
The indoor module can be run without heat pump, as
only an electric boiler, to produce heat and hot water,
for example before the heat pump is installed.
Close both the shut-off valves (QN4).
Enter menu 5.2.2 System settings and deactivate the
heat pump.
NOTE
Select operating mode auto or manual when
the indoor module is to run with the heat
pump.
Pump speed
One of the circulation pumps (GP1) in VVM 325 is fre-
quency controlled and adjusts itself using control and
external heating requirement.
LEK
0
10
20
30
40
50
60
0
200
400 600 800 1000 1200 1400 1600 1800 2000
Tillgängligt tryck cirkulationspump, GP12
Flöde (liter/timme)
Tillgängligt tryck [kPa]
Available pressure, circulation pump, GP1
Available pressure, circulation pump, GP1
Pressure
(kPa)
Flow (l/h)
Post-adjustment, venting
Air is initially released from the hot water and venting
may be necessary. If gurgling sounds can be heard from
the climate system, the entire system will require addi-
tional venting. The installation is vented via vent valves
(QM20), (QM22) and other climate systems through
their relevant vent valves. When venting, VVM 325
must be off.
