Nibe VVM 325 - Removing the Covers

Removing the covers
Front cover
1
2
LEK
LEK
LEK
LEK
LEK
1.
Remove the screws from the lower edge of the
front cover.
2.
Lift the cover out at the bottom edge and up.
Side covers
LEK
LEK
LEK
The side covers can be removed to facilitate the install-
ation.
NOTE
50 mm space required to remove the side
panels.
1.
Remove the screws from the upper and lower
edges.
2.
Twist the cover slightly outward.
3.
Move the hatch backwards and slightly to the side.
4.
Pull the cover to one side.
5.
Pull the hatch forwards.
NIBE™ VVM 325Chapter 2 | Delivery and handling6
