Nibe VVM 325 - 2 Delivery and Handling; Transport; Assembly; Supplied Components

Transport
VVM 325 should be transported and stored vertically
in a dry place. However, the VVM 325 may be carefully
laid on its back when being moved into a building.
Assembly
■
Position VVM 325 on a firm base that can take the
weight, preferably on a concrete floor or foundation.
Use the product's adjustable feet to obtain a horizont-
al and stable set-up.
30 - 50 mm
30 - 50 mm
15 - 40 mm
■
The area where VVM 325 is located must be
equipped with floor drainage.
Installation area
Leave a free space of 800 mm in front of the product.
All service on VVM 325 can be carried out from the
front.
800
NOTE
Leave 10-25 mm free space between the in-
door module and the wall behind for routing
of cables and pipes.
Supplied components
Room sensorOutside sensor
LEK
LEK
LEK
Current sensor
Location
The kit of supplied items is placed on top of the
product.
5Chapter 2 | Delivery and handlingNIBE™ VVM 325
2 Delivery and handling
