Nice DPRO500 User Manual

10 – English
EN
9
TECHNICAL SPECIFICATIONS
WARNINGS: •Alltechnicalspecicationsstatedhereinrefertoanambienttemperatureof20°C(±5°C).•NiceS.p.A.reservestherighttoapplymodications
to products at any time when deemed necessary, maintaining the same intended use and functionality.
Type Control unit for single-phase or three-phase motors with Nice mechanical or electronic limit switches
Power supply Three-phase
3~400VAC/3~230VAC(+10%-10%)50/60Hz
Single-phase
1~230VAC(+10%-10%)50/60Hz
Motor max power 2.2kW
Power in Standby < 5W
Fuse on power board F1:500mATypeF;F2,F3,F4:6.3ATypeT
Output 1 (with NDA040) Voltage free contact (relay), programmable with Oview
Output 2 (with NDA040) Voltage free contact (relay), programmable with Oview
Services output 24VDC(max100mA)betweeninput1(com)terminalandgnd(-)STOP8K2/OSEterminal(seeFig. 5)
“STOP SAFETY EDGE” Input Forcontactsthatarenormallyclosed,normallyopenorofthe8.2kΩconstantresistancetypeortheOSE
opticaltype;inauto-recognition(avariationfromthememorisedstatuscausesa“STOP”command)
“ALT” Input ForNormally-Closed(NC)contactsonthesafetycircuit
(OPEN) input ForNormallyOpen(NO)contacts
(CLOSE) input ForNormallyOpen(NO)contacts
ING1 (photo) Input ForNormally-Closed(NC)contacts,programmablewithOview
Radio connector SM connector for SMXI, SMXIS, OXI or OXIT receivers
Radio AERIAL Output 52ohmforRG58orsimilarcables(maximum10m)
Programmable functions FunctionsprogrammableviatheOviewProgrammingandControlUnit
Auto-recognition functions Auto-recognitionofthe“STOP”typeofdevice(OSEor8.2KΩresistance)
Operating temperature -20°C...+50°C
Protection class IP55
Vibration Installation free from movement, (e.g. on a brickwork wall)
Dimensions 310x210x160mm
Weight 2.5kg
