ID300/302 Integrated Motor Drive | Quick Start Commissioning
5 Quick Start Commissioning
This section details the commissioning of STANDARDKeypadconguration, which is the default. If
thiscongurationisnotsuitablefortheapplication,refertoSection5
http://www.leroy-somer.com/documentation_pdf/5512_en.pdf.
• Ensure that no damage or safety hazard could arise from the motor starting unexpectedly.
• By default, the correct motor rated current is set in Pr 05.007. DO NOT alter the rated current.
Otherwise,itwilla󰀨ectthethermalprotectionofthemotor.
• Iftheintendedmaximumspeeda󰀨ectsthesafetyofthemachinery,additionalindependentover-
speed protection must be used.
• TheID300/302haslowDCbuscapacitance(lmcapacitors)whichcaninducevoltagerippleon
the DC bus with low load conditions. The default settings of the drive address this phenomenon.
For more dynamic applications, it is advisable to adapt the setting.
5.1 Use of a Field Keypad RTC or ID-SIZE 1or ID-SIZE 3-Keypad
• IfthedriveisstartedusingaKeypad,itwillruntothespeeddenedbyakeypadreference.
Depending on the application, the keypad reference may not be acceptable. The user must check
in Pr 01.017 and ensure that the keypad reference has been set to 0.
IfthedefaultsettingsoftheID300/302standardcongurationarenotsuitablefortheapplication,the
parameterscanbemodiedusingtheKeypadoption.CommandscanbegivenfromtheKeypadusing
thefactorypresetconguration.RefertoSection5.1.6onpage37foradditionalinformation.
To connect the Keypad, refer to the relevant Keypad installation sheet for more details.
5.1.1 Understanding the Display
WARNING
!
WARNING
!
