ID300/302 Integrated Motor Drive | Quick Start Commissioning
Menu 0 Denition Main Menu Value
0.046 ADI1 Scale 7.008 1.000
0.047 ADI2 Scale 7.012 1.000
0.048 ADI1 invert 7.009 0
0.049 ADI2 invert 7.013 0
0.050 ADI1o󰀨set 7.030 0.00%
0.051 ADI2o󰀨set 7.031 0.00%
0.052 ADIO3 Scale 7.020 1.000
0.053 ADIO3 out 7.057 16
0.054 DI2 Destin 8.022 6.038
0.055 ADIO3 Yel 7.019 0.000
0.056 DI4 Dest 8.024 6.032
0.057 ADIO3 out 7.003 -
0.058 DI1 Control 8.081 0
0.059 Motor Rated Hz 5.006 Disable
0.060 Bipolar Ref 1.010 0
0.061 Thermistor 7.045 1.0
0.062 Boost V 5.015 0.002 or
0.063 Max Amps 11.032 0.001 to
0.064 Control Mode 5.014 0.002
0.069 User Security Code 11.030 -
0.070 Status Mode 2 11.019 4.020
0.071 Status Mode 1 11.018 2.001
0.072 Customer Scaling 11.021 1.000
0.073 Serial Baud Rate 11.025 115200
0.074 Serial Addresss 11.023 1
0.075 Reset Serial comm 11.020 0
0.076 Digital I/O word 8.02 -
0.077 Therm Value 7.047 -
0.078 Onboard Program 1.047 Run
0.079 OUP Status 11.048 -
0.08 Software Version 11.029 -
