Nidec Unidrive M400 series User Manual

Unidrive M400 Quick Start Guide 29
Issue Number: 8
00.048
Brake Controller
Brake Release
Frequency
0.00 to 20.00 Hz 1.00 Hz RW Num US
00.049
Brake Controller
Brake Apply
Frequency
0.00 to 20.00 Hz 2.00 Hz RW Num US
00.050
Brake Controller
Brake Delay
0.0 to 25.0 s 1.0 s RW Num US
00.051
Brake Controller
Post-brake Release
Delay
0.0 to 25.0 s 1.0 s RW Num US
00.053
Brake Controller
Initial Direction
Ref (0), Forward (1), Reverse (2) Ref (0) RW Txt US
00.054
Brake Controller
Brake Apply Through
Zero Threshold
0.00 to 25.00 Hz 1.00 Hz RW Num US
00.055
Brake Controller
Enable
Disable (0), Relay (1),
Digital IO (2), User (3)
Disable (0) RW Txt US
00.056 Trip 0 0 to 255
RO Txt ND NC PT PS
00.057 Trip 1 0 to 255
RO Txt ND NC PT PS
00.058 Trip 2 0 to 255
RO Txt ND NC PT PS
00.059 OUP Enable Stop (0) or Run (1) Run (1) RW Txt US
00.060 OUP Status -2147483648 to 2147483647 RO Num ND NC PT
00.065
Frequency Controller
Proportional Gain
Kp1
0.000 to
200.000 s/rad
0.100 s/rad RW Num US
00.066
Frequency Controller
Integral Gain Ki1
0.00 to
655.35 s
2
/rad
0.10 s
2
/rad
RW Num US
00.067
Sensorless Mode
Filter
4 (0), 5 (1),
6 (2), 8 (3),
12 (4), 20 (5) ms
4 (0) ms RW Txt US
00.069 Spin Start Boost 0.0 to 10.0 1.0 RW Num US
00.070 PID1 Output ±100.00 % RO Num ND NC PT
00.071
PID1 Proportional
Gain
0.000 to 4.000 1.000 RW Num US
00.072 PID1 Integral Gain 0.000 to 4.000 0.500 RW Num US
00.073
PID1 Feedback
Invert
Off (0) or On (1) Off (0) RW Bit US
00.074
PID1 Output Upper
Limit
0.00 to 100.00 % 100.00 % RW Num US
00.075
PID1 Output Lower
Limit
±100.00 % -100.00 % RW Num US
00.076
Action on Trip
Detection
0 to 31 0 RW Num ND NC PT US
00.077
Maximum Heavy
Duty Current Rating
0.00 to Drive HD Current Rating A RO Num ND NC PT
00.078 Software Version 0 to 99.99.99.99 RO Num ND NC PT
00.079 User Drive Mode Open loop (1), RFC A (2)
Open loop
(1)
RFC-A (2) RW Txt ND NC PT US
00.081 Reference Selected
-Pr 00.002 to Pr 00.002 or Pr 00.001
to Pr 00.002 Hz
RO Num ND NC PT
00.082 Pre-ramp Reference
-Pr 00.002 to Pr 00.002 or Pr 00.001
to Pr 00.002 Hz
RO Num ND NC PT
00.083
Final Demand
Reference
-Pr 00.002 to Pr 00.002 or Pr 00.001
to Pr 00.002 Hz
RO Num ND NC PT FI
00.084 D.C. Bus Voltage 0 to 415 V or 0 to 830 V RO Num ND NC PT FI
00.085 Output Frequency ±550.00 Hz RO Num ND NC PT FI
Parameter
Range
() Default ()
Type
OL RFC-A OL RFC-A
