VAA35001-R.3666.A

- A22 ･ S1 -

+36 +250

040915

０００１

Ａ１

△ △

Input the value.

[How to adjust]

・ Turn on the camera.

・ Connect the USB cable to PC.

・ Double-click on "DscCa1Di.exe".

・ Select "Lens Data” on "Test" of "LCD".

・ Input the value of the bar code, which is attached on the rear of the lens, into the text box of “Lens data Dialog”.

Then, click "Set".

・ Click “Exit” and close the dialog box.

11. Lens adjustment

[Preparations]

・ Turn on the collimator (J63090). (Do not connect the USB cable to PC yet.)

・ Turn on the camera.

・ Check the positions so that the chart center in the collimator should be at the center of the screen.

・ Turn off the camera once.

[Conditions]

・ Set the collimator and camera (i.e. the front surface of lens) as near as possible between them (approx.5.5 cm).

・ When the camera is mounted on the cradle, the camera must be right in front of the collimator.

※ Place the cradle in a horizontal position as much as possible. (Fig. 1)

（Fig.1）

Set it horizontally.

Adjustment collimator

Camera

※ ref. Page A1.










