Nikon Coolpix S1 Repair Manual

Parts List
VAA35001-R.3666.A
Part Number
部品名
Pcs,/
fig
Q'ty/
Part Code Part Name
Unit
No.
Order
Cool Pix S1 Silver
Barcode (Part Code) Remarks
Main Assembly
645-073-6063
ﾊﾞﾘｱﾓｰﾀｰﾕﾆｯﾄ
645-073-6063
BARRIER MOTOR UNIT
645-073-6162
ｺﾝﾄﾛｰﾙﾄﾂﾌﾟﾕﾆｯﾄ
645-073-6162
CONTROL TOP UNIT
645-073-6179
ｺﾝﾄﾛｰﾙﾊﾞｯｸﾕﾆｯﾄ
645-073-6179
CONTROL BACK UNIT
645-073-9903
LCD
645-073-9903
LCD
645-075-1547
ｽﾋﾟｰｶｰ
645-075-1547
SPEAKER
1S400-347
USBｿｹｯﾄ
1S400-347
USB SOCKET
636-069-2749
原産国ｼｰﾙ CHINA
636-069-2749
COUNTRY ORIGIN SEAL IV
636-086-0339
製品番号ｼｰﾙ (J)
636-086-0339
LABEL SERIAL 2-
636-086-0339-U
製品番号ｼｰﾙ (J)
636-086-0339-U
LABEL SERIAL 3-
636-086-0346
規格ｼｰﾙ
636-086-0346
LABEL RATING
636-086-9806
ﾗﾍﾞﾙﾎﾟｯﾌﾟ (U)
636-086-9806
LABEL POP (U)
636-087-6019
製品番号ｼｰﾙ (EU)
636-087-6019
LABEL SERIAL 4-
636-087-9737
ﾗﾍﾞﾙﾎﾟｯﾌﾟ （中国）
636-087-9737
LABEL POP (CK)
645-064-7970
ｶｰﾄﾞﾌﾟﾗｸﾞ
645-064-7970
CARD PLUG
*
*
5
*645-073-6063*
1
2
*645-073-6162*
1
2
1
*645-073-6179*
1
1
5
5
5
*645-073-9903*
1
*645-075-1547*
1
2
1
*1S400-347*
1
2 636-086-8366
5
*636-069-2749*
1
1
5
5
5
*636-086-0339*
1
*636-086-0339-U*
1
1
1
*636-086-0346*
1
1
5
*636-086-9806*
0-1
1
5
5
5
*636-087-6019*
1
*636-087-9737*
0-1
1
1
*645-064-7970*
1
2 636-086-8366 5
△
△
△
△
△
△
△
△
△
△x9 Apr 11, 2005 - 5 -

Nikon Coolpix S1 Specifications

General

Resolution	5.1 megapixels
Optical Zoom	3x
LCD Screen Size	2.5 inches
Image Sensor	1/2.5-inch CCD
ISO Sensitivity	Auto, 50, 100, 200, 400
Weight	118g
Digital Zoom	4x
Storage Media	SD card
Type	Compact
Focal Length	35-105 mm (35mm equivalent)
Battery	EN-EL8 Lithium-ion battery
Aperture	f/3.0 - f/5.4
LCD Monitor	2.5-inch TFT LCD
Dimensions	89.9 x 57.5 x 19.7 mm (3.5 x 2.3 x 0.8 in)
Shutter Speed	4 sec to 1/350 sec
