Page #68 background image
VAA35001-R.3666.A
- R1・ S1 -
Item Criteria Tools
External view
Gap/Difference in
height
Outside and inside
status
General components
Gap: 0.3mm or less
Difference in steps (height): 0.15mm or less
The 0.2mm convex section on the strap is excluded.
When the battery case is opened/closed:
 Gap in its periphery: 0.15mm or less
 Gap in the bottom: 0.2mm or less
 Difference between right and left:
   0.08mm or less (periphery)
  0.15mm or less (Difference in steps)
 Difference in steps (height): 0.3mm or less
No noticeable damage, stain, sink mark, welded mark, uneven-
ness, crack or oil exudation.
No noticeable noise, when pushing the main body.
(Make a visual check under fluorescent lamp and natural
sunshine.)
Visual check
Visual check
Operationality
Operation/Shaking/
Shock

Buttons/PWS
Mode slide SW
Neither irregular operations nor abnormal noise.
No malfunction.
(For operation check, shake the camera in operation.)
(Tap the camera with an open hand, and press it onto the
Linoleum-laid desk.)
No button stuck down.
Proper clicking feeling on each button.
"Click" sound is made on or after turning on the switch.
(Make a operation check in normal operation.)
(For operation check, press buttons one-sidedly/lightly, push them
down, and press continuously with chattering sound.)
Clear clicking feeling and smooth touching. Neither outstanding
"caught/rubbed-in-mechanism" touch nor gap .
(Make a operation check in normal operation.)
Secondary battery
INSPECTION STANDARDS
