Nikon Coolpix S1 Repair Manual

VAA35001-R.3666.A
- D2･ S1 -
REAR COVER
・ Remove 2 screws [#101].
・ Remove 4 screws [#102].
・ Remove 4 screws [#102]. ・ Unhook the rear cover [#029] and open the rear cover
[#029].
・ Remove the FPC from the connector.
Screw [#102]
Screw [#102]
Screw [#102]
Screw [#102]
Screw [#101]
FPC
Rear cover [#029]
Hook

Nikon Coolpix S1 Specifications

General

Resolution	5.1 megapixels
Optical Zoom	3x
LCD Screen Size	2.5 inches
Image Sensor	1/2.5-inch CCD
ISO Sensitivity	Auto, 50, 100, 200, 400
Weight	118g
Digital Zoom	4x
Storage Media	SD card
Type	Compact
Focal Length	35-105 mm (35mm equivalent)
Battery	EN-EL8 Lithium-ion battery
Aperture	f/3.0 - f/5.4
LCD Monitor	2.5-inch TFT LCD
Dimensions	89.9 x 57.5 x 19.7 mm (3.5 x 2.3 x 0.8 in)
Shutter Speed	4 sec to 1/350 sec
