Nikon D4 User Manual

128
Z
g: Aperture-Priority Auto
In aperture-priority auto, you choose the aperture while the camera
automatically selects the shutter speed that will produce the
optimal exposure.
Large apertures (low f-numbers) increase flash
range (0 192) and reduce depth of field, blurring objects behind
and in front of the main subject.
Small apertures (high f-numbers)
increase depth of field, bringing out details in the background and
foreground.
Short field depths are generally used in portraits to
blur background details, long field depths in landscape
photographs to bring the foreground and background into focus.
To choose an aperture
between the minimum and
maximum values for the lens,
rotate the sub-command dial
while the exposure meters are
on.
Aperture can be locked at
the selected setting (0 133).
Small aperture (f/36) Large aperture (f/2.8)
A Non-CPU Lenses (0 385, 388)
Use the lens aperture ring to adjust aperture.
If the maximum aperture of the lens has been
specified using the Non-CPU lens data item
in setup menu (0 229) when a non-CPU lens is
attached, the current f-number will be
displayed in the viewfinder and top control
panel, rounded to the nearest full stop.
Otherwise the aperture displays will show only the number of stops
(F, with maximum aperture displayed as FA) and the f-number must
be read from the lens aperture ring.
Sub-command dial

Nikon D4 Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	No
Total megapixels	16.6 MP
Image sensor size	- \
Image formats supported	JPG, NEF, RAW, TIF
Supported aspect ratios	3:2, 5:4, 16:9
Maximum image resolution	4928 x 3280 pixels
Image sensor size (W x H)	36 x 23.9 mm
Still image resolution(s)	4928 x 3280, 3696 x 2456, 2464 x 1640, 4096 x 2720, 3072 x 2040, 2048 x 1360, 3200 x 2128, 2400 x 1592, 1600 x 1064, 4096 x 3280, 3072 x 2456, 2048 x 1640, 4928 x 2768, 3696 x 2072, 2464 x 1384, 3200 x 1792, 2400 x 1344, 1600 x 896, 4928 x 3280, 3696 x 2456, 2464 x 1640, 3200 x 2128, 2400 x 1592, 1600 x 1064
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon D, Nikon F, Nikon-AF
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	51
Auto focusing (AF) modes	Centre weighted Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Spot Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 12800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	50 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	640x424@25fps, 640x424@30fps, 1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Internal memory	- MB
Compatible memory cards	CF, XQD
Display diagonal	3.2 \
Display aspect ratio	4:3
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Power source type	Battery
Product color	Black
Eye relief	18 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Direct sunlight, Fine, Flash, Fluorescent, Incandescent, Manual, Shade
Self-timer delay	2, 5, 10, 20 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, TUR, UKR
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
Battery type	EN-EL18
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Depth	90.5 mm
Width	160 mm
Height	156.5 mm
Weight	1182 g
Weight (including battery)	1340 g
