Nikon D4 User Manual

65
y
6 Start recording.
Press the movie-record button to start
recording.
A recording indicator and the
time available are displayed in the
monitor.
Exposure is set using matrix
metering and can be locked by pressing
the center of the sub-selector (0 135) or
altered by up to ±3 EV using exposure
compensation (0 137).
In autofocus
mode, the camera can be refocused by
pressing the AF-ON button.
A Audio
The camera can record both video and sound; do not cover the
microphone on the front of the camera during movie recording.
Note that the built-in microphone may record sounds made by the
lens during autofocus, vibration reduction, or changes to aperture.
A See Also
Frame size, microphone sensitivity, card slot, and ISO sensitivity
options are available in the Movie settings menu (0 74).
Focus
can be adjusted manually as described on page 59. The roles
played by the center of the multi selector, the Fn and Pv buttons,
and the center of the sub-selector can be chosen using Custom
Settings f1 (Multi selector center button; 0 327), g1 (Assign Fn
button; 0 340), g2 (Assign preview button; 0 341), and g3
(Assign sub-selector center; 0 342), respectively.
Custom Setting
g4 (Assign shutter button; 0 343) controls whether the shutter-
release button can be used to start movie live view, or to start and
end movie recording, or (when pressed all the way down) to take
photographs during movie recording.
Movie-record button
Recording indicator
Time remaining

Nikon D4 Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	No
Total megapixels	16.6 MP
Image sensor size	- \
Image formats supported	JPG, NEF, RAW, TIF
Supported aspect ratios	3:2, 5:4, 16:9
Maximum image resolution	4928 x 3280 pixels
Image sensor size (W x H)	36 x 23.9 mm
Still image resolution(s)	4928 x 3280, 3696 x 2456, 2464 x 1640, 4096 x 2720, 3072 x 2040, 2048 x 1360, 3200 x 2128, 2400 x 1592, 1600 x 1064, 4096 x 3280, 3072 x 2456, 2048 x 1640, 4928 x 2768, 3696 x 2072, 2464 x 1384, 3200 x 1792, 2400 x 1344, 1600 x 896, 4928 x 3280, 3696 x 2456, 2464 x 1640, 3200 x 2128, 2400 x 1592, 1600 x 1064
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon D, Nikon F, Nikon-AF
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	51
Auto focusing (AF) modes	Centre weighted Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Spot Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 12800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	50 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	640x424@25fps, 640x424@30fps, 1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Internal memory	- MB
Compatible memory cards	CF, XQD
Display diagonal	3.2 \
Display aspect ratio	4:3
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Power source type	Battery
Product color	Black
Eye relief	18 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Direct sunlight, Fine, Flash, Fluorescent, Incandescent, Manual, Shade
Self-timer delay	2, 5, 10, 20 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, TUR, UKR
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
Battery type	EN-EL18
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Depth	90.5 mm
Width	160 mm
Height	156.5 mm
Weight	1182 g
Weight (including battery)	1340 g
