230
t
4 Select Done.
Highlight Done and press
J.
The specified focal
length and aperture will be
stored under the chosen
lens number.
To recall lens data when using a non-CPU lens:
1 Assign non-CPU lens number selection to a camera
control.
Select Choose non-CPU lens number as the “Press +
command dials” option for a camera control in the Custom
Settings menu (0 332).
Non-CPU lens number selection can
be assigned to the Fn button (Custom Setting f3, Assign Fn
button, 0 328), the Pv button (Custom Setting f4, Assign
preview button, 0 333), or the center of the sub-selector
(Custom Setting f6, Assign sub-selector center, 0 333).
2 Use the selected control to choose a lens number.
Press the selected control and rotate the main or sub-
command dial until the desired lens number is displayed in
the top control panel.
J button
Lens number
Main command dial
Focal
length
Maximum
aperture
