Nikon D7000 User Manual

257
U
4 Adjust gain.
Highlight Image 1 or Image 2 and optimize
exposure for the overlay by pressing 1 or 3 to
select gain from values between 0.1 and 2.0.
Repeat for the second image. The default value is
1.0; select 0.5 to halve gain or 2.0 to double it.
The
effects are visible in the Preview column.
5 Preview the overlay.
Press 4 or 2 to place the cursor in the Preview
column and press 1 or 3 to highlight Overlay.
Press J to preview the overlay as shown at right
(to save the overlay without displaying a preview,
select Save).
To return to Step 4 and select new
photos or adjust gain, press W.
6 Save the overlay.
Press J while the preview is displayed to save the
overlay.
After an overlay is created, the resulting
image will be displayed full-frame in the monitor.
D Image Overlay
The overlay has the same photo info (including date of recording, metering, shutter speed,
aperture, shooting mode, exposure compensation, focal length, and image orientation),
white balance, and Picture Control as Image 1. The current image comment is appended to
the overlay; copyright information, however, is not copied. NEF (RAW) overlays use the
compression selected for Type in the NEF (RAW) recording menu and have the same bit
depth as the original images; JPEG overlays are saved using size-priority compression.

Nikon D7000 Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4928 x 3264 pixels
Image sensor size (W x H)	23.6 x 15.6 mm
Digital zoom	- x
Focal length range	- mm
Interface	USB 2.0
Power supply type	AC
Dimensions (WxDxH)	132 x 77 x 103 mm
Aperture range (F-F)	-
Camera shutter speed	1/3 - 1/8000 s
Effective sensor resolution	16900000 pixels
Compatible operating systems	Windows XP, Vista, 7 Mac OS X +
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	centre-weighted, spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE
Flash modes	Auto, Flash off, Manual
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.95 x
Viewfinder type	Optical
PictBridge	No
USB version	2.0
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	resizing, trimming
Photo effects	Black&White, Neutral
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	movie, single image, slide show
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL15
Power requirements	110 - 240 V
Battery life (CIPA standard)	1050 shots

Weight and Dimensions

Depth	77 mm
Width	132 mm
Height	103 mm
Weight	690 g
