The Display
1 3 4 5 62
7
10
8
13
11
9
12
Tx/Rx/OFF switch set to Tx (transmitter)
1 3 4 5 62
7
8
13
11
12
Tx/Rx/OFF switch set to Rx (receiver)
Description
0
1
If Tx/Rx/OFF switch is set to Tx, a is displayed and unit functions
as transmitter; if switch is set to Rx, b is displayed and unit func-
tions as receiver.
8
2
Indicates whether unit links to other units via pairing (j)
or ID (i).
9, 23
3 ID mode name. Not displayed in pairing mode. 23
4 Displayed when controls are locked. 3
5 Indicates whether beeps will sound. 16
6 Battery level. Displayed only when unit is not connected to camera. 5
